(1)Hot dip galvanized steel Frame

Covering

(1) PO/PEP/HDPE plastic film single layer film covering / double layers films one layer thickness: 120μm-200μm

(2) Polycarbonate: double/three layers

(3) Tempered glass

Single layer: 4mm/5mm

Double layer 5+6+5 mm

Can be customized according to customer requirements

Film multi-span greenhouse Parameters:

(1) Wind load: 0.55KN/㎡

(2) Snow load: 0.45KN/㎡

(3) Maximum rainfall: 140mm/h

(4) Planting bearing: 0.2KN /㎡

No.	Items	Description	Including Or Not
1	Steel Structure	Hot-galvanized steel pipe	Yes
2	Greenhouse film	There's a lot of thickness to choose from.	choose according to the clients requirements
3	Insect net	High quality polyrthylene as raw material	choose according to the clients requirements
4	Sun-shading net	Summer shade,block rain,moisture,cooling,winter spring heat preservation	choose according to the clients requirements
5	cooling system	It consists of cooling fans and cooling pad	choose according to the clients requirements
6	heating system	Hot water heating,hot air heating,electric heating	choose according to the clients requirements
7	ventilation system	Side windows and cooling fans	choose according to the clients requirements
8	Drip irrigation system	It can be customized according the greenhouse length and width	choose according to the clients requirements
9	Micro-sprinkler system	It can be customized according the greenhouse length and width	choose according to the clients requirements

Sichuan Aixiang Technology Co.,

ltd is located in Chengdu city, China , we are professional in variety of greenhouse , such as PC sheet greenhouse , PE Film greenhouse , and Glass greenhouse,tunnel greenhouse and solar greenhouse etc , All our products have passed ISO9001 Quality Standard, Our Main Market is Euro countries as Spain , And America countries as canada , usa, As well as Australia ..We Look foreward to establish long-term business relationship with you .

SICHUAN AIXIANG AGRICULTURAL TECHNOLOGY CO.,LTD

We are Sichuan Aixiang Agricultural Technology CO.,Ltd which is a greenhouse manufacturer in China started from 1995. And we have been doing exporting for more than 10 years till now. We have exported to USA, Canada, Turkmenistan, The UAE, Saudi Arabia, Japan, Nepal, Bangladesh, Pakistan, Australia, Sweden, France, Spain, Slovenia, Nigeria, Kenya, Tanzania, Cameroon, Congo, South Africa and Hongkong 28 countries and districts.

Our products cover all kinds of greenhouses including: plastic greenhouse, PC board glass greenhouse, tunnel greenhouse, blackout greenhouse , automatic intelligent high tech greenhouse with all the greenhouse accessories.

In addition, we provide you free design which made by our professional design team. And we can send technician of supervisor to your local if you need any help.

Welcome to visit us!
